Canon imagePROGRAF iPF605 Plotter Tech Specs

technical specifications

Main Features of Canon imagePROGRAF iPF605 Plotter

Type: 24 inch
Format: A1
Stand: No
Print technology: Pigment and Dye reactive ink, 5 colours (MBK x 2, BK, C, M, Y)
Print language: GARO, HP-GL/2, HP RTL (standard)
Print resolution (dpi): 2400 x 1220
Main unit size (D x H x W): 997 x 670 x 344 mm
Main unit with stand (D x H x W): 997 x 870 x 993 mm
Main unit with palette (D x H x W): 1140 x 914 x 645 mm
Weight: 45 kg

Canon imagePROGRAF iPF605 Plotter Performance

PrintSpeed (m2/h): Plain Paper: 0:33 (Fast-CAD), Coated Paper: 1:19 (Standard-CAD), Photo Glossy Paper: 2:44

Canon imagePROGRAF iPF605 Plotter Supplies

Media print width (inch/cm): 10″ (254mm), B4 (257mm), A3+ (329mm), 14″ (356mm), 16″ (407mm), A2 (420mm), A2+/17″ (432mm), B2 (515mm), A1 (594mm), 24″ (610mm)
Maximum rolls length: 18 m
Lateral edge (inch/cm): Roll Paper: 5 mm, Cut Sheet (Top Loading/Cassette): 5 mm, Cut Sheet (Front Loading) : 5 mm
Printhead: PF-03
Printhead configuration: 6 colors
Print media: Roll Paper: Standard paper 80gsm, Standard Paper 90gsm, Matt Coated Paper 90gsm, Glossy Photo Quality Paper 190 gsm/ 240gsm/ 300gsm, Satin Photo Quality Paper 190 gsm/ 240gsm/ 300gsm, Photo Realistic Paper 210gsm, Pearl Photo Paper 260gsm, Matt Coated Paper 120gsm/ 140 gsm/ 180gsm, Opaque White Paper 120gsm, High Resolution Self-adhesive Graphic paper 140gsm, High Resolution Barrier Paper 180gsm, Glossy Proofing Paper 195gsm, Semi-Glossy Proofing Paper 195gsm, Semi-Glossy Proofing Paper 195gsm/ 255gsm
Compatible toner: PF-102 (130ml) cartridges (MBK, BK, C, M, Y), PF-03, MC-16 Printhead
Maximum roll diameter: 150 mm
Maximum roll length: 18 m
Cartridge capacity (ml): 130

Canon imagePROGRAF iPF605 Plotter – Connectivity Tech Specs

Protocols: IPX/SPX (Netware 4.2(J), 5.0(J), 6.0(J)) SNMP (Canon-MIB), HTTP, TCP/IP, AppleTalk
Network: EEE1394 – 1995, P1394a, Half duplex, Data/Strb differential serial
Standard interface: USB 2.0
Power consumption (w): 100

Canon imagePROGRAF iPF605 Plotter Parameters

Noise level (dB): On: 49, Standby: 35
Recommended temperature (ºC): 15 – 30
Relative Humidity (% RH): 10 – 80%
Voltage (V): AC 100 – 120V (50/60Hz), AC 220 – 240V (50/60Hz)
Display: 160 x 128, Key x 12, LED x 5
Display type: LCD
